Gocator 2600 Profiler

The industry-leading Gocator® 3D smart sensor family introduces 4K+ resolution laser profiling to measure microscopic features or larger objects. These factory pre-calibrated sensors come equipped with custom optics and a powerful 9-megapixel imager to deliver 4200 data points per profile for high-resolution 3D scanning and inspection across wide fields of view.

CHARACTERISTICS

  • RESOLUTION X 2.5 um - 550 um
  • REPEATABILITY 0.22 um - 12 um
  • FOV 10.2 mm - 2,000 mm (X)
  • MEASUREMENT RANGE 5 mm - 1,550 mm
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • PROTECTION IP67

Gocator 3000 Snapshot

Gocator 3D snapshot sensors combine blue-LED structured light with built-in 3D measurement tools for high-precision area scanning and inspection. As opposed to lasers that are used to scan moving objects, snapshot sensors use a single snapshot scan to inspect stationary objects or objects with start/stop motion.

CHARACTERISTICS

  • RESOLUTION (XY) 20 um - 121 um
  • FIELD OF VIEW (XY) 71 mm x 98 mm - 175 mm x 282 mm
  • REPEATABILITY (Z) 2.0 um - 4.6 um
  • MEASUREMENT RANGE (Z) 150 mm
  • PROTECTION IP67
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP

In-Sight 3D-L4000

The In-Sight® 3D-L4000 is a breakthrough in three-dimensional (3D) vision technology. This unique vision system combines 3D laser displacement technology with a smart camera allowing factory engineers to quickly, accurately, and cost effectively solve a wide variety of inspections on an automated production line. The patented speckle-free blue laser optics, an industry first, acquires high quality 3D images and on-board high-performance processing powers a comprehensive set of true 3D vision tools, without the need for external processing. 3D vision tools are set up as easily as 2D vision tools thanks to the familiar and robust In-Sight spreadsheet environment.

CHARACTERISTICS

  • RESOLUTION 28.6 um - 479.2 um
  • REPEATIBILITY 0.5 um - 2 um
  • FOV 55 mm - 460 mm
  • MEASUREMENT RANGE 106 mm - 745 mm
  • COMMUNICATIONS Gigabit Ethernet Interface
  • INPUT VOLTAGE 24 VDC
  • PROTECTION IP65

Gocator 1300 Series

High-Speed 3D Laser Point Profile Sensors
Use Gocator laser point profile sensors for high-speed dimensional measurements (e.g. surface roughness, object thickness) in closed-loop automation systems.

  • Pre-calibrated and ready to measure
  • Scalable to a synchronized multiple sensor network
  • Small footprint

CHARACTERISTICS

  • RESOLUTION 0.0004 mm - 0.0250 mm
  • LINEARITY 0.01 mm - 2.0 mm
  • MEASUREMENT RANGE 20 mm - 2000 mm
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • PROTECTION IP67

Gocator 2300 Profiler

Workhorse 3D Laser Line Profile Sensors

Gocator 2300 sensors deliver robust 3D inspection across a wide range of high-speed, high-volume applications.

  • Megapixel imager. 1280 points per profile resolution
  • Field-of-view up to 1260 mm
  • Measurement range up to 800 mm

CHARACTERISTICS

  • RESOLUTION X 0.014 mm - 0.375 mm
  • RESOLUTION Z 0.0018 mm - 0.092 mm
  • REPEATABILITY 0.4 um - 12 um
  • FOV 18 mm - 1260 mm
  • MEASUREMENT RANGE 25 mm - 800 mm
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • PROTECTION IP67

Gocator 2100 Profiler

Entry-Level 3D Laser Line Profile Sensors

Use Gocator® 2100 for cost-effective inline quality inspection applications where the highest resolution is not required.

  • VGA imager. 640 points per profile resolution
  • Field-of-view up to 1260 mm
  • Measurement range up to 1350 mm

CHARACTERISTICS

  • RESOLUTION X 0.028 mm - 0.75 mm
  • RESOLUTION Z 0.0018 mm - 0.092 mm
  • REPEATABILITY 0.4 um - 12 um
  • FOV 18 mm - 1260 mm
  • MEASUREMENT RANGE 25 mm - 800 mm
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • PROTECTION IP67

Gocator 2400 Profiler

High-Resolution 3D Laser Line Profile Sensors

Gocator 2400 sensors are designed for 100% inspection of difficult targets such as microphotographs on small electronic parts and dark materials such as tire treads/sidewalls and rubber sheets in high-speed in-line applications.

  • 2 megapixel imager. Up to 1940 dots per profile resolution
  • Up to 2000 mm field of view (FOV)
  • Measuring range up to 1525 mm
  • Available in RED and BLUE laser models for optimal performance and maximum flexibility in your scanning applications

CHARACTERISTICS

  • RESOLUTION X 0.0058 mm - 0.250 mm
  • RESOLUTION Z 0.0002 mm - 0.012 mm
  • REPEATABILITY 0.0002 mm - 0.012 mm
  • FOV 18 mm - 1260 mm
  • MEASUREMENT RANGE 10 mm - 2000 mm
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • PROTECTION IP67

Gocator 2500 Profiler

High-Speed 3D Blue Laser Line Profile Sensors

The 2500 series are high-speed 3D laser line profile sensors in the most compact and advanced Gocator® design yet. These sensors achieve inspection speeds up to 10 kHz—including scan, built-in 3D surface measurement, and pass/fail control—to meet inline production speed.

  • Blue laser + custom optics for optimal performance on dark and specular targets
  • IIoT-ready with built-in web server, configure with any web browser
  • Built-in tools for 3D alignment, part segmentation, and 3D feature extraction
  • Native support for multi-sensor networking

CHARACTERISTICS

  • RESOLUTION X 0.008 mm - 0.27 mm
  • REPEATABILITY 0.2 um - 2 um
  • FOV 13 mm - 518 mm
  • MEASUREMENT RANGE 6 mm - 595 mm
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • PROTECTION IP67

Gocator 2880 Profiler

Dual Triangulation 3D Laser Line Profile Sensors
Two cameras maximize scan coverage and minimize occlusions for applications such as primary log scanning.

  • Megapixel imager. 1280 points per profile resolution
  • Field-of-view up to 1260 mm
  • Measurement range up to 800 mm

CHARACTERISTICS

  • RESOLUTION X 0.375 mm
  • RESOLUTION Z 0.092 mm
  • FOV 390 mm - 1260 mm
  • MEASUREMENT RANGE 800 mm
  • COMMUNICATIONS EtherNet/IP, Modbus TCP, RS-232, TCP/IP
  • INPUT VOLTAGE 24 VDC - 48 VDC
  • PROTECTION IP67

Visual Robotics VIM-303

VIM-303 is a complete vision system and robot controller in a single package with 3D vision, 12 megapixel image capture, and onboard-lighting. It can be arm-mounted or fixed-mounted, and visually locates and tracks static or moving objects with ease — and no encoders. Pick and place programming is accomplished with code-free drag-and-drop blocks, or via our Python API. VIM-303 turns your UR robot into a vision-enabled, multi-purpose tool.

CHARACTERISTICS

  • RESOLUTION 12MP Color; 1MP Stereo
  • DEPTH OF FIELD 80 mm - Infinity
  • FIELD OF VIEW 550 mm x 408 mm (at 400mm)
  • ON-BOARD Hi-Res Auto-Focus Color Camera; Stereo Cameras; 4-bank lighting; Image Processor; Motion Controller
  • PROTECTION IP65/67
  • INPUT POWER PoE <15W
  • COMMUNICATIONS Gigabit Ethernet
